VZ 950

VZ 950DK

Demanding tasks require more powerful and more advanced solutions. The VZ 950 is the perfect machine to handle material of almost any kind. Due to its modular structure the time consumption and maintenance costs are kept very low and that makes this shredder an extremely powerful, efficient and reliable recycling machine.


Features at a glance

  • Patented T-blade profile guarantees precise cutting process (energy savings up to 15%)
  • Two tilting hoppers for optimal feeding of the material to the tool shafts
  • Automatic reversing function protects against fracture of the cutting tools
  • Powerful diesel engine with 768 hp – also available with electric drive (2 x 250 kW)
  • Very high throughput – depending on material and tool shafts up to 180 t/h
  • Low wear and maintenance costs and maintenance friendly modular design



Technical Data

ModelPerformance (KW/HP)Dimensions LxWxH (mm)Shafts (mm)Weight (kg)
VZ 950 DK565 kW (768 hp)10,500 x 3,400 x 3,8002,50042,000
VZ 950 DT565 kW (768 hp)13,000 x 3,000 x 4,0002,50039,000
VZ 950 E2x 250 kW9,700 x 3,000 x 3,7002,50035,000

*Technical changes, print errors and mistakes reserved. All data are approximate values of the standard model. Latest Revision: May 2015.
